Centrifugal Water Pumps (Type TDCV)

Centrifugal Water Pumps  (Type TDCV)
Centrifugal Water Pumps (Type TDCV)
Product Code : 07
Product Description

Centrifugal Water Pumps (Type TDCV)

We are considered to be one of the most professional manufacturers, exporters and suppliers of Centrifugal Water Pumps (Type TDCV). These are precisely engineered by employing optimum quality raw materials and advanced technology. Our team of quality controllers closely examines these pumps on various predefined quality parameters. These water pumps are very apt for water supply purposes over long distances as well as for irrigation of the agricultural farms. The offered gamut of Centrifugal Water Pumps (Type TDCV) is known for its robust construction and long working life.

Specifications



Design Features

  • The pump is made for coupling with electric motor, diesel engine with the help of belt.

  • The direction of rotation is clockwise viewing from pulley end.

  • The pump is solid in construction, vibration proof and easy in handling.

  • The pump is supported with robust ball bearings.

  • Casing is made of high quality close grained cast iron with well-designed volute way ensuring smooth flow with gradual changes in velocity and is hydraulically tested before final assembly.

  • Impeller is of single end suction, shrouded type made of special Grey Iron with high finish and impeller is dynamically as well as statically balanced.

  • Shaft is made from high quality steel and accurately ground finished within the manufacturing tolerances, and the size of the shaft is designed for transmitting maximum power without vibrations.

  • Supporting frame is robustly constructed to carry shaft, single as well as double bearings and brass bush.

  • Stuffing box is of liberal depth for accommodating sufficient gland packing. Easy access to stuffing box is an outstanding feature of Supporting Frame, facilitating convenient replacement of Gland packing.

Application

  • Water supply from fountains, lakes, rivers; water transport through the pipelines over long distances

  • Irrigation of the Agricultural Farms.

Technical Data

  • Suction / Discharge Diameter : upto 6 inch

  • Capacity : upto 56 lps

  • Pumping head : upto 22 meter

  • Suction head : Max.6 meter

  • Prime Mover Capacity : upto 5 to 20 hp

  • Revolution Per Minute : 1440 rpm

  • Max. Working Pressure : 3.5 Bar
